Acorid CS1110PG 8 10/100M PoE ports + 2 10/100/1000M Uplink ports PoE Switch

Product Description :

CS1110PG is a gigabit uplink 8-port 100G PoE switch developed by ACORID, providing 8*10/100M adaptive RJ45 ports and 2 Gigabit RJ45 Uplink ports. Each RJ45 port supports MDI/MDIX auto-flip and wire-speed forwarding functions. All downlink ports support PoE+ power supply, with single port PoE power up to 30W and maximum PoE output power of 96W. As a PoE powered device, it can automatically detect and identify the standard powered devices and supply power to them through the network cable.

The device is plug-and-play, no configuration, simple and convenient to use, and is the best choice for wireless coverage of security monitoring in hotels, campuses, factory dormitories, and small and medium-sized enterprises.

Features :

• Large buffer design, high-definition video does not freeze

• Support IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow

• Each RJ45 port supports MDI/MDIX auto flip and wire-speed forwarding functions

Operating Mode :

• Provides three exchange modes.

• Standard mode: All ports can communicate freely after opening. Suitable for ordinary data transmission environment

• VLAN mode: After opening, all downstream ports cannot communicate with each other, which can isolate broadcast storms and prevent ARP viruses

• Extend mode: After opening, the rate of all downlink ports becomes 10M, and the transmission distance can reach 250m.

PoE Power Supply Capability :

• The maximum output power of a single port can reach 30W

• SmartLink power management, StepLink step-by-step start function to escort the safe and stable operation of Kedi PoE switches;

Product Reliability :

• The host has a low power consumption design and natural heat dissipation to ensure stable operation of the product.

• High redundancy design, providing long-term stable PoE power output.

• 0~45℃ working temperature improves product stability in a wide temperature environment
